VT5 - Titan grade6 pipe
General characteristics
Alloy VT5 is one of the first domestic industrial titanium alloys. It was developed by VIAM in 1950-ies. Foundry option ВТ5Л. VT5−1 have been proposed VIAM in 1958 and has become the equivalent of foreign brands Ti-5Al-22,5 Sn. This alloy has a single phase α-structure. It does not harden with heat treatment.
| The chemical composition of the VT5−1 (GOST 19807 — 91) | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| The percentage content of impurities, no more | The percentage within | Other | |||||||||
| C | N | H | Si | Fe | Zr | O | Sn | Ti | Al | V | |
| 0,1 | 0,05 | 0,015 | 0,12 | 0,3 | 0,3 | 0,15 | 2 — 3 | 88,833 — 93,4 | 4,3 — 6 | 1,2 | 0.3% |
Brand VT5−1kg, having a low content of impurities is designed to operate at cryogenic temperatures. Used in impeller pumps, designed to supply liquid hydrogen.
Dignity marks VT5−1, VT5
| Alloy | t° plaul. | UD. weight | Technology | Properties | Application |
|---|---|---|---|---|---|
| VT5 | 980−1030° | 4,41 g/cm3 |
Low technological plasticity in the processing pressure. Easy to weld all types of welding. Excellent castability. |
Low technological plasticity and medium toughness. Aluminium increases the heat resistance and strength, but lower workability. | Designs and details that long-term work at a temperature of 350−400°. |
| VT5−1 | 950−990° | 4,42 g/cm3 |
In the casting process ingots, you may experience some difficulties with the introduction of tin. | Tin and aluminum to enhance heat resistant and strength properties. Tin contributes to the improvement of processability during the processing pressure. Average strength. | Designs and details of aircraft, which are long-term work at a temperature of 400−450°. |
Use
Cryogenic and corrosion resistance, heat resistance, plasticity, good weldability low sensitivity to notches, allow a wide use of series pipe W in shipbuilding, mechanical engineering, rocketry, aviation, chemical and cryogenic industry.
| The physical characteristics of VT-5 | |
|---|---|
| The temperature at which the received data characteristics, °C | 20°C |
| Coefficient of thermal conductivity at 200 °C [1/ °C] | Up 10.47 |
| Density [g/cm3] | 4,4 |
| The modulus of elasticity of 1 of the kind E [MPa]x10-5 | 1,05 |
| Specific heat capacity at 200 °C [j/(kg·deg)] | 0,586 |
Limit crackbrain. strength sin [MPa] Rod otogi. GOST 26492−85 |
685−735 |
| Electrical resistivity, Mhmm2/m | Of 1.08 |
