- Nickel alloys
Incoloy, Inconel, Nimonic, Hastelloy, haynes
Large assortment of Nickel-based alloys in stock LLC «AVEK global» can satisfy any consumer. The quality of the finished product is ensured absolute compliance with all technological norms of production. The order execution time is the shortest. If you have any questions, you will receive detailed advice from experienced managers. In the implementation of wholesale orders the company provides flexible system of discounts.
Short marochnik foreign specialty steels and stainless steel alloys
GOST | GOST | DIN | UNS | or | Round | Wire | Sheet | Forging | Pipe |
---|---|---|---|---|---|---|---|---|---|
NP-2 | Nickel 200 | Nr. W. 2.4060 Nr. W. 2.4066 |
N02200 | ||||||
NP-2 | Nickel 201 | Nr. W. 2.4061 Nr. W. 2.4068 |
N02201 | ||||||
Monel Mngmt 28−2,5−1,5 | Monel 400® | Nr. W. 2.4360 Nr. W. 2.4361 |
N04400 | ||||||
405 Monel® | N04405 | ||||||||
Monel K500® | N05500 | ||||||||
~ KHN60VT | Inconel 600® | Nr. W. 2.4816 | N06600 | ~ ЭИ868 | |||||
~ KHN60VT | Inconel 601® | Nr. W. 2.4851 | N06601 | ~ ЭИ868 | |||||
~ ХН56МВКЮ | Inconel 617® | Nr. W. 2.4663 | N06617 | ~ ЭП109 | |||||
KHN75MBTJU | Inconel 625® | Nr. W. 2.4856 | N06625 | ЭИ602 | |||||
~ KHN60JU | Inconel 718® | Nr. W. 2.4668 | N07718 | ~ ЭИ559А | |||||
KHN70MVTJUB | Inconel X 750® | Nr. W. 2.4669 | N07750 | ЭИ598 | |||||
KHN32T | Incoloy 800® | Nr. W. 1.4876 | N08800 | ЭИ670 | |||||
KHN32T | Incoloy 800H® | Nr. W. 1.4876 | N08810 | ЭИ670 | |||||
KHN32T | Incoloy 800HT® | Nr. W. 1.4876 | N08811 | ЭИ670 | |||||
~ KHN38VT | Incoloy 825® | Nr. W. 2.4858 | N08825 | ~ ЭП703 | |||||
Hastelloy C22® | Nr. W. 2.4602 | N06022 | |||||||
~ KHN65MVU | Hastelloy C276® | Nr. W. 2.4819 | N10276 | ~ ЭП760 | |||||
Н70МФ | Hastelloy B-2® | N10665 | EP 49 | ||||||
Hastelloy X® | Nr. W. 2.4665 | N06002 | |||||||
Vascomax 250® / Maraging C250 | 92890 K | ||||||||
Vascomax 300® / Maraging C300 | 93120 K | ||||||||
Vascomax 350® / Maraging C350 | |||||||||
Rene 41® | 07041 N | ||||||||
Multimet N155® | 30155 R | ||||||||
Haynes 25® | 30605 R | ||||||||
Haynes 188® | 30188 R | ||||||||
Waspalloy® | 07001 N | ||||||||
MP35N® | 30035 R | ||||||||
MP159® | 30159 R | ||||||||
Cobalt Alloy 6B | 30006 R | ||||||||
36N | Invar 36® | Nr. W. 1.3912 | 93600 K | ||||||
42N | Invar 42® | 94200 K | |||||||
29NK | Kovar® | 94610 K | |||||||
79NM | Permalloy® | ||||||||
Al6XN® | N 08367 | ||||||||
Ni-Span® C902 | 09902 N | ||||||||
Jethete® M152 | S64152 | ||||||||
Alloy A286 | S66286 | ||||||||
Alloy 330 | N08330 N |
Form of delivery | ||||
---|---|---|---|---|
Name | Long, mm | Diameter, mm | Width, mm | Thickness, mm |
Round | 500−5000 | 1−300 | ||
Sheet g/K | 700−2000 | 700−1000 | 3.5−28 | |
Sheet of Kh/K | 700−2000 | 700−1000 | 0.02−3.2 | |
wire | 0.016−12 | |||
Outer diameter | Length | Wall | Note | |
---|---|---|---|---|
Pipe | 0.5−325 | 1000−9000 | 0.05−24 | The weight of the pipe not more than 350 kg |
Inconel (Inconel)
High-temperature Nickel-based alloy Inconel in its composition contains up to 15% Cr and 9% Fe. The alloy was developed in USA for the manufacture of jet engines. Domestic analogues of the alloy are ХН73МБТЮ and KHN80TBJU. This alloy to a temperature of 900 °C has high toughness and strength, while at lower temperature (-78°C) Inconel is no sensitivity to the incision.
Inconel is easily welded, for hardening welded joints heat treatment is carried out.
Nimonic
Superalloy Nimonic Nickel-based, developed in 1942 in the UK at the company «Monde nickel company». Nimonic contains in its structure aluminum, titanium, and chromium. Domestic analogues of the alloy are ХН55ВМТФКЮ and KHN80TBJU. To obtain the required properties, and has developed a number of varieties alloy, which contain Al and 0.5−6% Ti -0,2−4%, Cr -10−21%. Legarrette alloy with molybdenum not more than 6%, cobalt not more than 22%, and other components. The melting point of the alloy varies depending on the chemical. composition and varies in the temperature range of 1310 — 1390 °C, it can be used the best grades at a temperature not exceeding 1000 °C. Nimonic easily amenable to hot working under pressure and much more difficult to cold treatment. It is produced in the form of sheets, pipes, forgings, rods. From Nimonic to produce parts of jet engines in aviation, rocket science .
Haseleu (Hastelloy)
The Nickel-based alloy Hastelloy, resistant to corrosion. Hasteloy in its composition contains chromium up to 23%, iron up to 29%, molybdenum up to 30%, carbon up to 0.15%. Domestic analogues of the alloy are Н70М28Ф and Х15Н65М16 V. Some of the brands of alloy alloyed with W 5%, Si not more than 10%, not more than 2.5%, si, V, Ta, Nb and other components. Hastelloy is resistant to organic environments of hydrochloric, phosphoric, sulfuric, acetic acids, has resistance to formic acid, chlorine ions of fluorine etc. Hastelloy produced in the form of sheets, castings, wire rods. It is used as heat resistant material in the manufacture of chemical equipment.
