General characteristics
Alloy VT5 is one of the first domestic industrial titanium alloys. It was developed by VIAM in 1950-ies. Foundry option ВТ5Л. VT5−1 have been proposed VIAM in 1958 and has become the equivalent of foreign brands Ti-5Al-22,5 Sn. This alloy has a single phase α-structure. It does not harden with heat treatment.
Manufacture and dignity VT5−1 plate, sheet
| Prefabricated | Heat treatment | Thickness (mm) | Strength (MPa) | KCU j/cm3 | Plasticity of δ% |
|---|---|---|---|---|---|
| Sheet VT5−1 | Warm rolling | P | 1055 | --- | 7,9% |
| D | 1037 | --- | 5,3% | ||
| Sheet VT5−1 | Annealing | 0,8 — 1,2 | 735 — 932 | --- | More than 15% |
| Annealing | 1,5 — 1,8 | --- | More than 12% | ||
| Annealing | 2,0 — 6,0 | --- | More than 10% | ||
| Annealing | 6,5 — 10,0 | --- | More than 8% | ||
| Sheet VT5−1 | Отжиг800° | 2 MMD | 844 | --- | 16.8% of |
| Отжиг750° 20 min. | 3 MMP | 867 | --- | 12.6% of | |
| 3 MMD | 872 | --- | 20% | ||
| Vacuum отжиг750° 1 h | 3 MMP | 813 | --- | 18.5% of | |
| 3 MMD | 823 | --- | 22.3% of | ||
| Sheet VT5−1 | Annealing | 0,3 — 10,5 | More than 735 | --- | 8 — 15% |
| Plate VT5−1 | Annealing | 11 — 35 | 735 — 930 | More than 6% | |
| Delivery condition | 12 — 20 | 735 — 932 | More than 6% | ||
| 21 — 60 | More than 5% |
P — transverse cutting direction samples; D — longitudinal; T — Tangenziale In — high-rise.
Heat resistance
Highest voltage — creep strength, under whose influence the material is deformed by a given amount at a given temperature.
Long-term strength
Is the maximum voltage that Deplete the material after a certain time at a given temperature. Thus, at an elevated temperature with an increase in the duration of the load decreases the tensile strength.
| Physical characteristics 5V | |
|---|---|
| The temperature at which the received data characteristics, °C | 20°C |
| Coefficient of thermal conductivity at 200 °C [1/ °C] | Up 10.47 |
| Density [g/cm3] | 4,4 |
| The modulus of elasticity of 1 of the kind E [MPa]x10-5 | 1,05 |
| Specific heat capacity at 200 °C [j/(kg·deg)] | 0,586 |
Limit crackbrain. strength sin [MPa] Sheet otogi. GOST 26492−85 |
735−930 |
| Electrical resistivity, Mhmm2/m | Of 1.08 |
Use
Cryogenic and corrosion resistance, heat resistance, plasticity, good weldability low sensitivity to notches, allow a wide use of the alloys of the series W, shipbuilding, mechanical engineering, rocketry, aviation, chemical and cryogenic industry.
