Sheet, wire VT1-0 titanium grade 2
Characteristics of the alloy VT1−0
Brand VT1−0 contains chemically pure titanium is 99.5%. Foil, tape, sheet of this alloy has high corrosion and chemical resistance, heat resistance, negligible temperature coefficient of expansion, low density (4,505 g/cm3), high plasticity. Foil, tape, sheet of biologically inert, are resistant to prolonged action of moisture, chlorinated water, sea water, withstand high pressure.
| The thickness of the semi-finished product (mm) | Name | Heat treatment | Plasticity of δ% | Strength (MPa) | KCU j/cm3 |
|---|---|---|---|---|---|
| 0,3 — 0,4 | Sheet | Delivery condition | More than 25% | 392 — 540 | --- |
| 0,3 — 0,5 | Sheet | Annealing | .>20 — 30 | More than 400 | --- |
| 0,5 — 1,8 | Sheet | Delivery condition | More than 30% | 392 — 540 | --- |
| 2,0 — 6,0 | Sheet | Delivery condition | More than 25% | 392 — 540 | --- |
| 6,5 — 10,0 | Sheet | Delivery condition | More than 20% | 392 — 540 | --- |
| 16 | Sheet | Hot rolling | 31,2 | 467 | --- |
| 20 | Sheet | Hot rolling | 30,0 | 461 | --- |
| 25 | Sheet | Hot rolling | 30,0 | 480 | --- |
| 2 | Sheet | Annealing | 51,0 | 338 | --- |
| 0,3 — 0,5 | Tape | Annealing | More than 45 | 343 — 490 | --- |
| 0,55 — 1,5 | Tape | Annealing | More than 35 | 343 — 490 | --- |
| 0,05 — 0,08 | Foil | Annealing | --- | more than 400 | --- |
| 0,08 | Foil, fine grain | Annealing | 18 — 26 | 540 — 600 | --- |
| 0,05 — 0,03x90 mm | Foil | Vacuum annealing | 31,2 | 510 | --- |
| 0,08 | Foil, large grain | Annealing | 8 — 10 | 640 — 700 | --- |
Annealing temperature tape and sheet 520 — 570 °C, t° partial annealing is 475−485°C
Disadvantages
The main disadvantage is the high labour intensity of production. Titanium melts only inert gases or in vacuum, because the liquid melt actively interacts with any of the atmospheric gases. Strip, sheet VT1−0 are difficult to machining, have the highest strength (390−540 MPa)
| The physical characteristics of VT1−0 | |
|---|---|
| The temperature at which the received data characteristics, °C | 20°C |
| Coefficient of linear thermal expansion αx106 at 100 °C [1/ °C] | 8,2 |
| Density [g/cm3] | 4,5 |
| The modulus of elasticity of 1 kind, E [MPa]x10-5 | 1,12 |
| The specific heat of the alloy at 20 °C [j/(kg·deg)] | 0,540 |
| Coefficient thermal conductivity), l[W/(m·deg)] | Of 18.85 |
| Electrical resistivity, Mhmm2/m | 1,6 |
Application
Advantages of tape, foil and sheet brand VT1−0 can be used as an ideal material for the petrochemical industry, energy, construction, aviation, rocket production, shipbuilding. From the tape and sheet are made of stamped parts, which allow to reduce the weight of the structures, while increasing reliability and durability. Biological inertness VT1−0 allows the manufacture of surgical instruments (tweezers, scalpels), plates intended for plasty of pelvic bones and skull, joint prostheses, dental bridges and crowns, ophthalmic implants, centrifuges, containers, separators and more.
Buy at best price
A large range of products from alloy VT1−0 in stock LLC «AVEK global» can satisfy any consumer. The price is formed taking into account technological features of production without the inclusion of additional costs. The quality of the finished product is ensured strict compliance with all technological norms of production. The timing of orders is minimal. If you have any questions, you consult experienced managers. For wholesale orders the company provides flexible system of discounts.
