Nichrome wire Х15Н60 - 2.4867 - nikrothal 60®
Properties of Nichrome brand X15N60-N
— high electrical resistance;
— increased resistance to formation of oxide, thermal fatigue, scale at 1200 ° C;
— high resistance to thermal changes.
Using
Furnaces for drying and firing, high temperature furnaces, resistance elements, industrial heaters, heaters.
| Designation | NiCr 60 15 | |
|---|---|---|
| Material | 2.4867 | |
| ALLOY | Ni60Cr15 | |
| DIN | 17470/17471 | |
| ASTM | --- | |
| UNS designation | N06004 | |
| AMS | --- | |
| CHEMICAL STABILITY OF BRAND X15N60-N, (%) | ||
| Ni (Nickel) | Not more than 59.0 | |
| Cr (Chrome) | From 14.0 to 17.0 | |
| Fe (Iron) | The basis | |
| C (Carbon) | Not higher than 0.10 | |
| Mn (Manganese) | Not higher than 1.0 | |
| Si (Silicon) | From 1.0 to 1.75 | |
| Cu (Copper) | Not higher than 0.5 | |
| Al (Aluminum) | Not higher than 0.3 | |
| Ti (Rare Earth) | Not more than 0. 04 | |
| Rest | --- | |
| PROPERTIES MECHANICAL BRANCHES Х15Н60-Н AT ROOM TEMPERATURE | ||
| Relative extension | More than 20% | |
| Number of bends | More than 7 times | |
| PROPERTIES PHYSICAL BRANCHES Х15Н60-Н AT ROOM TEMPERATURE | ||
| Hardness | From 200 to 220 HB | |
| Density | 8.2 g / cm³ | |
| Breaking force | From 637 to 784 MPa | |
| Specific electrical resistance | 1.12 Ohm * mm2 / m | |
| Maximum Operating Temperature | 1150 ° C | |
| Melting temperature | 1390 ° C | |
| Magnetic properties | Weakly magnetic | |
| Diameter from 6,0mm | At Temp. = 1100 ° C | More than 4 thousand hours. |
| Diameter from 3,0 to 6,0mm | At the Temp. = 1050 ºС | More than 2 thousand hours. |
| Diameter from 1,5 to 3,0mm | At the Temp. = 1050 ºС | More than 2 thousand hours. |
| Diameter from 0,4 to 1,5mm | At the Temp. = 1050 ºС | More than 1 thousand hours. |
