Alloyed tool steel
General characteristics
Alloy steel is an alloy of iron with molybdenum, cobalt, vanadium, tungsten and others elements, which at a certain way of processing and production give the material the required characteristics and structure.
Marking
The main alloying elements are identified by the following letters: B — niobium, G-manganese, — tungsten, D — copper, cobalt, E-selenium, M is molybdenum, X — chrome, P — phosphorus, N-Nickel, P — CE, T — titanium, s — silicon f — V, C — Zirconia, s — aluminium. The numbers that are after the letters denote the rounded content of these elements. When the content of the element is less than 1.5% figure for the letter index is not assigned. Additive carbon is specified at the beginning of the brand hundredths of a percent (for structural steels) or tenths (of the steels).
Production
Alloy tool steel is produced according to GOST 5950−2000. This standard normalizes the production of strips, rods, coils hot rolled, forged, calibrated with special surface treatment of tool and alloy steels, the percentage of grades 4KHMNFS, 3KH2MNF, 9ХФМ in the form of forgings, bars, strips, billets, pipes and other metal products.
| Chemical composition of alloy steels, in percent. | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Mark | P | Ni | S | Mn | Si | C | Cr | Cu | W | Mo | V | |
| 5KHV2SF | <0.03 | - | <0.03 | 0.15 -0.45 | 0.8 -1.1 | 0.45 -0.55 | 0.9 — 1.2 | 0.15 — 0.3 | 1.8 — 2.3 | - | - | |
| 8KH4V2MFS2 | <0.03 | <0.35 | <0.03 | 0.2 — 0.5 | The 1.7−2 | 0.8 — 0.9 | 4.5 — 5.1 | <0.3 | 1.8 — 2.3 | 0.8 — 1.1 | 1.1 — 1.4 | |
| CVH | <0.03 | <0.35 | <0.03 | 0.8 — 1.1 | 0.1 -0.4 | 0.9 — 1.05 | 0.9 — 1.2 | <0.3 | 1.2 — 1.6 | <0.3 | - | |
| Hardness after annealing the material 8KH4V2MFS2, MPa | HB 10 -1 = 255 |
|---|---|
| Hardness after annealing the material 5KHV2SF, MPa | HB 10 -1 = 229 |
| Hardness after annealing the material CVH, MPa | HB 10 -1 = 255 |
Buy at best price
LLC «AVEK global» offers the most favorable conditions of steel products. The offered range of alloy steels can satisfy any customer. The volume of purchase and additional conditions of supply depends on the price. Carrying out wholesale orders, you can count on company-provided flexible system of discounts. Our managers are always ready to provide advice. A large range will not leave you without a choice. The timing of orders is minimal. All products are certified. Quality is guaranteed by strict observance of technological norms of production.
